Easy Guide on How to Install a Rearview Camera

Installing a rearview camera in your vehicle can greatly enhance safety by providing better visibility when reversing. It’s a straightforward upgrade that allows you to avoid obstacles and spot pedestrians, especially in tight spaces. In this guide, we’ll walk you through the steps to install a rearview camera yourself, along with the average cost of buying one.

Why Install a Rearview Camera?

A rearview camera is a great tool for avoiding accidents while reversing. Many vehicles come with a built-in camera, but if yours doesn’t have one, adding one is a simple and effective solution. Rearview cameras can help you:

Avoid collisions when backing up.
Spot pedestrians, especially children and pets.
Make parking in tight spaces easier.
Enhance overall safety by offering a wider field of view.

What You’ll Need

To install a rearview camera, you’ll need a few tools and supplies:

Rearview camera kit: This typically includes the camera, wiring harness, monitor, and other accessories needed for installation.
Screwdriver: For removing panels or screws.
Wrenches: To secure any connections.
Electrical tape: For securing wires and avoiding any shorts.
Drill (if needed): To make holes for mounting the camera.
Power source: A 12V power source is usually needed to power the camera.
Double-sided tape or mounting bracket: To attach the camera to your car.

Step-by-Step Guide to Installing a Rearview Camera

1. Choose the Right Rearview Camera Kit

Before you begin, it’s important to choose the right rearview camera kit for your vehicle. Some kits are designed for DIY installation, while others might require professional help. The kit should include the camera, monitor, wiring harness, and any necessary mounting brackets. You can find a variety of options online, ranging from basic systems to more advanced models with features like parking lines or wireless connections.

2. Remove the Trunk or Rear Panels

The rearview camera needs to be mounted at the back of your car, usually near the license plate. Depending on your vehicle, you may need to remove some interior panels or trim to access the wiring areas. Use a screwdriver or trim removal tool to carefully take off any panels without damaging them.

3. Mount the Rearview Camera

Once you have access to the rear area of your car, mount the camera in the desired location. Most people mount the camera near the license plate, as this provides an optimal view. If your kit comes with a bracket, use that to secure the camera. If not, you can use double-sided tape to hold it in place temporarily while you make the electrical connections.

If your camera requires drilling, carefully mark where the holes should go, drill the holes, and mount the camera securely using the screws provided in the kit.

4. Connect the Wiring

Now that the camera is mounted, it’s time to connect the wiring. The camera will need to be wired to a power source and the monitor. Typically, the camera wires are run through the car’s interior, from the back to the front, following the existing wiring pathways. You may need to remove interior panels or run wires under the carpet to hide them.

The camera needs to be connected to a 12V power source, usually found at the rear light area. The wiring kit should include instructions for connecting the camera to the reverse light power. Make sure to connect the ground wire securely and use electrical tape to prevent any exposed wires from causing a short circuit.

Once the camera is powered, connect the video cable to the monitor. The monitor can be mounted on the dashboard, attached to your rearview mirror, or placed on the dash using a mounting bracket.

5. Install the Monitor

The monitor needs to be installed where you can easily see it while driving. Most kits come with a small screen that can be attached to your dashboard or rearview mirror. If you are installing a wireless system, it might require a mounting bracket for secure placement.

Once the monitor is in place, run the necessary video cables from the camera to the monitor. If you’re using a wired system, this usually involves connecting a video cable from the rear camera to the monitor located in the front of your car. If you’re using a wireless system, you may not need to connect cables between the camera and the monitor, as they communicate wirelessly.

6. Test the Camera

Before securing all the panels back into place, test the camera to ensure it’s working properly. Put the car in reverse, and the monitor should display the view from the rear camera. Check the quality of the image and adjust the camera’s angle if necessary.

Average Cost of a Rearview Camera

The cost of a rearview camera can vary depending on the features and quality of the system. On average, you can expect to pay the following:

Basic rearview camera kit: $50 – $150 CAD. These typically come with a basic camera and monitor, offering standard features.
Mid-range rearview camera kit: $150 – $300 CAD. These kits may include better image quality, parking lines, or more durable mounting options.
High-end rearview camera kit: $300 – $600+ CAD. These systems may include additional features such as wireless connectivity, larger screens, and enhanced image resolution.

If you prefer to have the camera professionally installed, the cost of installation can range from $100 to $300 CAD, depending on the complexity of the installation and the shop’s rates.

When to Bring in a Professional

While installing a rearview camera yourself is a manageable task, there are times when you may want to consult a professional. If you’re not comfortable with electrical wiring or drilling holes into your car, it’s best to seek help from a professional installer. Additionally, if you’re installing a high-end system that requires more intricate wiring or integration with your car’s onboard electronics, professional installation may be worth the cost.

Professional installation also ensures that everything is set up correctly, and the camera works as intended. Toronto Auto Detailing Inc. and other professional auto shops can assist with rearview camera installations, ensuring a seamless process and optimal camera performance.

Conclusion

Installing a rearview camera is a valuable upgrade that improves safety and convenience when driving and reversing. With a little time and patience, you can install it yourself, following the easy steps outlined in this guide. Make sure to choose a quality camera kit and take your time to wire it properly. If you’re unsure about any part of the process or would prefer professional assistance, don’t hesitate to contact a trusted auto professional for help.

By adding a rearview camera to your car, you can drive with greater peace of mind, knowing you have enhanced visibility at the rear of your vehicle.
